A/C SPECIFICATIONS:
Length: 120’ 3”
Wingspan: 200’ 0”
Height: 47’ 11”
Gross Weight: 162,000 lbs.|
Approx. Empty Wt.: 88,000 lbs.
POWERPLANT:
Engine(s): Four Wright R3350-24
Piston Radial
Horsepower (Each): 2500 H.P.
FUEL: PERFORMANCE:
Type: Avgas 100 Cruise Speed: 165 Kts.
Capacity: (Normal) 21,600 lbs. (13,600 litres) Target / Drop Speed: 120 Kts
Consumption: 3,950 lbs./hr. (2,500 litres) Stall Speed (Operating Wt.): 89 Kts.
Operational Endurance: 5.5 hrs. Pick Up Time: 20-30 Sec.
TANKING SYSTEM:
Tank Type: Compartmented with probes
Max. Capacity: Tank – 27,240 litres, Foam concentrate capacity – 2,270 litres
